Description :
Tent Width:3m-50m
Length no limited.
The length can be extended by 3m such a s 6m 9m,12m,15m...Customized size is available.
or extended by 5m a bay,such as 15m,20m,25m,30m,35m,40m...Customized size is available
| Span width Width(m) | Side height(m) | Top height (m) | Bay distance(m) | Aluminum profile(mm) |
| 6 | 2.6 | 3.7 | 3 | 84X48X3 |
| 8 | 2.6 | 4 | 3 | 84X48X3 |
| 9 | 2.6 | 4.3 | 3 | 84X48X3 |
| 10 | 2.6 | 4.4 | 3 | 84X48X3 |
| 10 | 3 | 4.8 | 5 | 122X68X3 |
| 12 | 2.6 | 4.8 | 3 | 100X48X3 |
| 12 | 3 | 5.2 | 5 | 122X68X3 |
| 15 | 4 | 6.4 | 5 | 166X87X3 |
| 18 | 4 | 6.9 | 5 | 204X110X4 |
| 20 | 4 | 7.2 | 5 | 204X110X4 |
| 25 | 4 | 8 | 5 | 204X110X4 |
| 30 | 4 | 8.9 | 5 | 256X111X5 |
| 35 | 4 | 9.8 | 5 | 300X125X8mm |
| 40 | 4 | 10.6 | 5 | 300X125X8mm |
| 45 | 4 | 11.4 | 5 | 300X125X8mm |
| 50 | 4 | 12.3 | 5 | 350X125X8mm |
Tents structure material:High Reinforce Aluminum, anti-rust surface, GB6061-T6;
Tents fabric material: Cover material is 850 g/2 for tent roof and 660 g/2 Double PVC-Coated Polyester for walls.
Which is flame retardant, UV resistance, waterproof, comply to DIN 4102 B1, M2 ( European standard ),
Tent connector:trong hot-dip galvanized steel
and all of our tents can stand -30°to +70°temperature
max wind speed allowance: 100km/h.
Our tents advantages:
1: With 100% inner space,without poles in tent middle place.
2: Tent size can be changeable,If customer buy one set 20x50m tent,tent size can change to 20x40m,20x35m,20x30m...it is 5m a bay.
Installed by sections.
3: Very strong tent,Aluminum structure can be used for more than 25 years.
PVC fabric cover can be used for around 10 years.and PVC cover can Replaceable.
FAQ :
*Q1.Does your company is a factory?
A:Yes, we are a directly factory, We assure you all prices are based on factory.
*Q2: How can I calculate the tent size I need?
A:We must first determine tent usage. If the tent with tables and chairs in it,one person need 1.5 square meters.
If tent without tables,one person need 1 square meter.
*Q3.Does your company accept customized tent?
A:Yes, we can make the tent according to customers different need.
*Q4. Does your company provide any help to install the tent?
A:Yes, usually we will send manual guide books or Video to help customer installation.If customer need our engineer come to their country to help install,that is also workable.
*Q5: Does your tent be able to install repeatedly?
A:Yes, Our tents can be assembled and dismantled and repeatedly.They installed sections by sections,Aluminum structure can be used for 25 years,PVC fabric can be used for 8-10 years.
